Large Wheel Loaders

992

The Cat® 992 Large Wheel Loader has set the standard in its size class for more than 50 years, delivering industry-leading productivity, unparalleled reliability and long life. Today’s 992 raises the bar. Compared to the 992K, the new 992 is up to 48% more efficient and 32% more productive, thanks to higher payload for improved pass match, increases in rimpull and breakout force, and an optimized linkage design. Extended component replacement intervals plus increased filter and turbo life help reduce maintenance costs. These improvements — and many more — combine to provide significant savings over the life of the machine for the lowest owning and operating costs in the industry. With both standard and high-lift configurations, the 992 offers the ideal pass match for fleets of Cat 775, 777 and 785 trucks.

Net Power
607kW
Gross Power - SAE J1995 at 1,750 rpm - Tier 4/HRC (Highly Regulated Country) - Standard
671kW
Gross Power - SAE J1995 at 1,750 rpm - Tier 4/HRC - High Ambient
699kW
Find a centre

Overview

The Cat® 992 Large Wheel Loader has set the standard in its size class for more than 50 years, delivering industry-leading productivity, unparalleled reliability and long life. Today’s 992 raises the bar. Compared to the 992K, the new 992 is up to 48% more efficient and 32% more productive, thanks to higher payload for improved pass match, increases in rimpull and breakout force, and an optimized linkage design. Extended component replacement intervals plus increased filter and turbo life help reduce maintenance costs. These improvements — and many more — combine to provide significant savings over the life of the machine for the lowest owning and operating costs in the industry. With both standard and high-lift configurations, the 992 offers the ideal pass match for fleets of Cat 775, 777 and 785 trucks.

Specifications
  • Net Power607kW
  • Gross Power - SAE J1995 at 1,750 rpm - Tier 4/HRC (Highly Regulated Country) - Standard671kW
  • Gross Power - SAE J1995 at 1,750 rpm - Tier 4/HRC - High Ambient699kW
  • Gross Power - SAE J1995 at 1,750 rpm - Tier 2/LRC (Less Regulated Country) - Standard676kW
  • Gross Power - SAE J1995 at 1,750 rpm - Tier 2/LRC - High Ambient704kW
  • Gross Power - ISO 14396 at 1,750 rpm - Tier 4/HRC - Standard659kW
  • Gross Power - ISO 14396 at 1,750 rpm - Tier 4/HRC - High Ambient687kW
  • Gross Power - ISO 14396 at 1,750 rpm - Tier 2/LRC - Standard666kW
  • Gross Power - ISO 14396 at 1,750 rpm - Tier 2/LRC - High Ambient694kW
  • Net Power - SAE J1349 at 1,750 rpm - Tier 4/HRC - Standard607kW
  • Net Power - SAE J1349 at 1,750 rpm - Tier 4/HRC - High Ambient607kW
  • Net Power - SAE J1349 at 1,750 rpm - Tier 2/LRC - Standard614kW
  • Net Power - SAE J1349 at 1,750 rpm - Tier 2/LRC - High Ambient614kW
  • Bore145mm
  • Stroke162mm
  • Displacement32.1l
  • Peak Torque - SAE J1995 - Tier 4/HRC - Standard @ 1,200 rpm4765N·m
  • Peak Torque - SAE J1995 - Tier 4/HRC - High Ambient @ 1,300 rpm4820N·m
  • Peak Torque - SAE J1995 - Tier 2/LRC - Standard @ 1,200 rpm4796N·m
  • Peak Torque - SAE J1995 - Tier 2/LRC - High Ambient @ 1,350 rpm4841N·m
