Cat® Large Wheel Loaders are designed with durability built in, ensuring maximum availability through multiple life cycles. With optimized performance and simplified serviceability, our machines allow you to move more material efficiently and safely at a lower cost per ton. The new 986K builds upon this legacy of durability, performance, safety, operator comfort, serviceability and sustainability.
Net Power
278kW
Operating Weight
44818kg
Gross Power - ISO 14396
335kW
Overview
Cat® Large Wheel Loaders are designed with durability built in, ensuring maximum availability through multiple life cycles. With optimized performance and simplified serviceability, our machines allow you to move more material efficiently and safely at a lower cost per ton. The new 986K builds upon this legacy of durability, performance, safety, operator comfort, serviceability and sustainability.
Specifications
Engine
- Net Power278kW
- Gross Power - ISO 14396335kW
- Peak Power Speed - 1,600 rpm - SAE J1995340kW
- Peak Power Speed - 1,600 rpm - SAE J1995 (DIN)340kW
- Peak Power Speed - 1,600 rpm - ISO 14396335kW
- Peak Power Speed - 1,600 rpm - ISO 14396 (DIN)335kW
- Rated Speed - 2,000 rpm - EEC 80/1269278kW
- Rated Speed - 2,000 rpm - EEC 80/1269 (DIN)278kW
- Rated Speed - 2,000 rpm - ISO 9249278kW
- Rated Speed - 2,000 rpm - ISO 9249 (DIN)278kW
- Rated Speed - 2,000 rpm - SAE J1349278kW
- Rated Speed - 2,000 rpm - SAE J1349 (DIN)278kW
- Bore137mm
- Stroke171.5mm
- Displacement15.2l
- Peak Torque - 1,200 rpm - SAE J19952411N·m
Attachments
COMPATIBLE WITH
Cat® Detect with Smart Camera
The Cat® Detect with Smart Camera safety technology utilizes a smart camera, an in-cab display and alerts to help your operator keep track of people near the machine.
View ModelsCat® Detect with Surround Cameras
The Cat® Detect with Surround Camera system uses three or four cameras and an in-cab display to give operators a view of their surroundings. It's an effective way to increase safety at the site.
View ModelsRear Object Detection for Wheel Loaders
Rear Object Detection for wheel loaders is a two-part system providing enhanced blind spot awareness. Radar provides visual and audible alerts when objects enter a safety proximity zone, while a camera allows the operator to see what's behind the machine when reversing.
View Models
