Landfill Compactors

816

Purpose-built for landfill operation, the Cat 816 delivers features, performance and efficiency that come from over 50-plus years of industry leadership. Field-proven protection and integrated technologies provide peak availability and optimized landfill performance.

View all specifications View attachments View all downloads

Save for later Add to compare

Gross Power - SAE J1995:2014

212KW

Net Power - SAE J1349:2011

186KW

Net Power - ISO 9249:2007

186KW

Find a centre

Overview

Cat Landfill Compactors are designed with durability built in, ensuring maximum availability through multiple life cycles. With optimized performance and simplified serviceability, our machines allow you to operate more efficiently and safely. Introduced in 1972, the 816 has been the industry leader for over 50 years. Focused on helping our customers succeed, we have continued to build upon each new series. The 816 continues our legacy of reliability, performance, safety, operator comfort, serviceability, and efficiency.

Resources

816 (11A) Product Brochure (Global)

816 Compactor Key Features (Global)

816 (11A) Technical Specifications (Global)

Specifications

Gross Power - SAE J1995:2014212kW
Net Power - SAE J1349:2011186kW
Net Power - ISO 9249:2007186kW
Engine Power - ISO 14396:2002205kW
Peak Torque ( 1,400 rpm )1223N·m
Net Power - SAE J1349:2011186kW
Net Power - ISO 9249:2007186kW
Gross Power - SAE J1995:2014213kW
Engine Power - ISO 14396:2002205kW
Peak Torque ( 1,400 rpm )1016N·m
Bore105mm
Stroke135mm
Displacement7.01l
High Idle Speed2270r/min
Low Idle Speed800r/min
Maximum Altitude - Without Derating3000m

Attachments

COMPATIBLE WITH

Cat® Detect with Smart Camera

The Cat® Detect with Smart Camera safety technology utilizes a smart camera, an in-cab display and alerts to help your operator keep track of people near the machine.

View Models

Cat® Detect with Surround Cameras

The Cat® Detect with Surround Camera system uses three or four cameras and an in-cab display to give operators a view of their surroundings. It's an effective way to increase safety at the site.

View Models

Cat Compact with Compaction Algorithm

Compact with Compaction Algorithm combines advanced compaction measurement, in-cab guidance for operators, and reporting capabilities for managers. Includes a Global Navigation Satellite System (GNSS) receiver and mapping display.

View Models
