At 535 HP and over 123,000 lb. operating weight, the 836K Landfill Compactor leads the class in reliability, performance, safety, operator comfort, serviceability, and efficiency. From a family of machines with over 20 years of landfill experience, the 836K is powered with field-proven technologies to keep operations running at their peak.
Landfill Compactors
Gross Power
419.0KW
Net Power
370.0KW
Bore
145.0MM
Overview
Cat Landfill Compactors are designed with durability built in, ensuring maximum availability through multiple life cycles. With optimized performance and simplified serviceability, our machines allow you to operate more efficiently and safely. Introduced in 1993, the 836 has been the industry leader for over 20 years. Focused on helping our customers succeed, we have continued to build upon each new series. The 836K continues our legacy of reliability, performance, safety, operator comfort, serviceability, and efficiency.
Specifications
Engine
- Gross Power419.0kW
- Net Power370.0kW
- Bore145.0mm
- Stroke183.0mm
- Displacement18.1l
- Low Idle Speed750.0r/min
- Gross - SAE J1349419.0kW
- Rated Power (Net ISO 14396)412.0kW
- Net Power - SAE J1349 - Converter Drive - Torque Rise52.0%
- Net Power - SAE J1349 - Converter Drive - Gross Power370.0kW
- Maximum Altitude - Without Derating2286.0m
- Net Power - SAE J1349 - Direct Drive - Gross Power370.0kW
- High Idle Speed2120.0r/min
- Net Power - SAE J1349 - Direct Drive - Torque Rise52.0%
- Rated Power (Lab)414.0kW
- Maximum Gross Torque - 1,300 rpm3085.0N·m
Attachments
COMPATIBLE WITH
Cat® Detect with Smart Camera
The Cat® Detect with Smart Camera safety technology utilizes a smart camera, an in-cab display and alerts to help your operator keep track of people near the machine.
Cat® Detect with Surround Cameras
The Cat® Detect with Surround Camera system uses three or four cameras and an in-cab display to give operators a view of their surroundings. It's an effective way to increase safety at the site.
Cat Compact with Compaction Algorithm
Compact with Compaction Algorithm combines advanced compaction measurement, in-cab guidance for operators, and reporting capabilities for managers. Includes a Global Navigation Satellite System (GNSS) receiver and mapping display.
