The Cat® 914K Compact Wheel Loader features an optimized Z-bar linkage that combines the digging efficiency of a traditional Z-bar loader with tool carrier capabilities for great performance and versatility. With parallel lift and high tilt forces throughout the working range you can safely and confidently handle loads with precise control.
Compact Wheel Loaders
Maximum Gross Power
75KW
Maximum Gross Power - Maximum Engine Speed
2350R/MIN
Maximum Gross Power - SAE J1995
76KW
Overview
The Cat® 914K Compact Wheel Loader features an optimized Z-bar linkage that combines the digging efficiency of a traditional Z-bar loader with tool carrier capabilities for great performance and versatility. With parallel lift and high tilt forces throughout the working range you can safely and confidently handle loads with precise control.
Specifications
Engine
- Maximum Gross Power75kW
- Maximum Gross Power - Maximum Engine Speed2350r/min
- Maximum Gross Power - SAE J199576kW
- Maximum Gross Power - ISO 1439675kW
- Maximum Gross Power - ISO 14396 (DIN)75kW
- Rated Net Power - Rated Engine Speed2200r/min
- Rated Net Power - SAE J134973kW
- Rated Net Power - ISO 924974kW
- Rated Net Power - ISO 9249 (DIN)74kW
- Displacement4.4l
- Bore105mm
- Stroke127mm
- Maximum Gross Torque - SAE J1995415N·m
- Maximum Gross Torque - ISO 14396410N·m
- Maximum Net Torque - SAE J1349400N·m
- Maximum Net Torque - ISO 9249405N·m
Attachments
COMPATIBLE WITH
3.66 m (12 ft)
3.66 m (12 ft)
3.66 m (12 ft)
3.66 m (12 ft)
1550 mm (61 in)
Cat® Pallet Fork Carriages for are designed to meet a wide variety of material handling needs. Use carriages with different length fork tines for moving bulky or palletized materials on construction and industrial sites, handling bagged fertilizer and seed at landscaping and nursery sites.
1524 mm (60 in)
Cat® Pallet Fork Carriages for are designed to meet a wide variety of material handling needs. Use carriages with different length fork tines for moving bulky or palletized materials on construction and industrial sites, handling bagged fertilizer and seed at landscaping and nursery sites.
1550 mm (61 in)
Cat® Pallet Fork Carriages for are designed to meet a wide variety of material handling needs. Use carriages with different length fork tines for moving bulky or palletized materials on construction and industrial sites, handling bagged fertilizer and seed at landscaping and nursery sites.
2134 mm (84 in)
Cat® Construction Fork Carriages for Small Wheel Loaders are wider than pallet fork carriages and are designed for heavy duty applications. Fork tines can be configured to allow tines to either swing or stay in a fixed position.
1.7 m3 (2.2 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.7 m3 (2.2 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.3 m3 (1.7 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.3 m3 (1.7 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.4 m3 (1.8 yd3), Pin On, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.4 m3 (1.8 yd3), ISO Coupler, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.2 m3 (1.6 yd3), ISO Coupler, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.2 m3 (1.6 yd3), IT Coupler, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.5 m3 (2.0 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.4 m3 (1.8 yd3), IT Coupler, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.6 m3 (2.1 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.3 m3 (1.7 yd3), Pin On, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.6 m3 (2.1 yd3), Pin On, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.6 m3 (2.1 yd3), ISO Coupler, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.9 m3 (2.5 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.5 m3 (2.0 yd3), IT Coupler, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.9 m3 (2.5 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.5 m3 (2.0 yd3), Pin On, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.6 m3 (2.1 yd3), IT Coupler, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.5 m3 (2.0 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.9 m3 (2.5 yd3), Pin On, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.8 m3 (2.4 yd3), Pin On, Bolt-On Cutting Edge
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.7 m3 (2.2 yd3), Pin On, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.8 m3 (2.4 yd3), Pin On, Bolt-On Teeth
Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.
1.6 m3 (2.1 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® Flat Floor Buckets are Performance Series, General Purpose Buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
1.7 m3 (2.2 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® Flat Floor Buckets are Performance Series, General Purpose Buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
1.9 m3 (2.5 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® Flat Floor Buckets are Performance Series, General Purpose Buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
1.8 m3 (2.4 yd3), ISO Coupler, Weld-On Teeth
Cat® Flat Floor Buckets are Performance Series, General Purpose Buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
1.6 m3 (2.1 yd3), ISO Coupler, Weld-On Teeth
Cat® Flat Floor Buckets are Performance Series, General Purpose Buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
1.5 m3 (2.0 yd3), ISO Coupler, Weld-On Teeth
Cat® Flat Floor Buckets are Performance Series, General Purpose Buckets that incorporate a specially designed long floor and a rear cutting edge to provide optimum results and productivity when performing light grading or back-dragging—while retaining all the premium loading-characteristic of the Performance Series.
2.5 m3 (3.3 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
2.5 m3 (3.3 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
2.5 m3 (3.3 yd3), Pin On, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
3.0 m3 (3.9 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
3.0 m3 (3.9 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
3.0 m3 (3.9 yd3), Pin On, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
3.5 m3 (4.6 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
3.5 m3 (4.6 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
3.5 m3 (4.6 yd3), Pin On, Bolt-On Cutting Edge
Cat® Light Material Performance Series Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
2.5 m3 (3.3 yd3), Fusion™ Coupler, Bolt-On Cutting Edge
Cat® Light Material Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
3.0 m3 (3.9 yd3), Fusion™ Coupler, Bolt-On Cutting Edge
Cat® Light Material Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
3.5 m3 (4.6 yd3), Fusion™ Coupler, Bolt-On Cutting Edge
Cat® Light Material Buckets leverage many of the same features found in the General Purpose Bucket but with higher volume capacities to handle less dense materials such as top soil, fertilizer, wood chips and many more.
BA25 Manual
Hydraulic and Manual Cat® Angle Brooms for Skid Steer Loaders, Compact Track Loaders, Backhoe Loaders, Compact Wheel Loaders and Small Wheel Loaders are ideal for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.
2134 mm (84 in)
Cat® Log & Lumber Fork Carriages are used to load, unload, move deck, sort and feed the mill. Their flat fork tines and raised guards are designed specifically for use in handling both unfinished logs and stacked lumber.
3941 mm (155 in)
Move pipe, concrete blocks, highway dividers and other construction materials quickly and easily with an Extendable Material Handling Arm. Length of the arm is manually adjustable to match load and reach requirements.
4203 mm (165 in)
Move pipe, concrete blocks, highway dividers and other construction materials quickly and easily with an Extendable Material Handling Arm. Length of the arm is manually adjustable to match load and reach requirements.
2.5 m3 ( 3.3 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® High Dump Buckets for Compact Wheel Loaders feature greatly increased dump height over standard material handling buckets. Whether loading trucks, feeding compactors or just working in the pile, Cat High Dump Buckets offer the performance you need.
2.1 m3 ( 2.7 yd3), IT Coupler, Bolt-On Cutting Edge
Cat® High Dump Buckets for Compact Wheel Loaders feature greatly increased dump height over standard material handling buckets. Whether loading trucks, feeding compactors or just working in the pile, Cat High Dump Buckets offer the performance you need.
2.5 m3 ( 3.3 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® High Dump Buckets for Compact Wheel Loaders feature greatly increased dump height over standard material handling buckets. Whether loading trucks, feeding compactors or just working in the pile, Cat High Dump Buckets offer the performance you need.
2.1 m3 ( 2.7 yd3), ISO Coupler, Bolt-On Cutting Edge
Cat® High Dump Buckets for Compact Wheel Loaders feature greatly increased dump height over standard material handling buckets. Whether loading trucks, feeding compactors or just working in the pile, Cat High Dump Buckets offer the performance you need.
BP25
Pickup Brooms for Cat® Skid Steer Loaders, Backhoe Loaders, Integrated Toolcarriers, and Wheel Loaders sweep and deposit materials into an integrated hopper for easy removal and dumping.
VisionLink®
VisionLink® is a cloud-based software application that takes the guesswork out of fleet management with key insights to maximize performance - regardless of fleet size or equipment manufacturer. Receive equipment data seamlessly to your desktop or mobile device, all from a convenient centralized solution to make informed decisions at every turn.
